PS-1410-601 Black 12V Magnetic reed switch proximity sensor
PS-1410-601 Black 12V Magnetic reed switch proximity sensor
PS-1410-601 Black 12V Magnetic reed switch proximity sensor
Product Name : PS-1410-601 Black 12V Magnetic reed switch proximity sensor
A proximity sensor consists of two parts: a magnetic part which contains a permanent magnet inside; and a sensor part which contains a reed switch. When these two magnetic parts get close enough, by electromagnetic induction,it will connect the electrical circuit. And this distance is called "detection distance." Usually, one of these two parts is installed on a stable position, and the other one is installed on a moveable object to connect or disconnect the circuit.
Support Hotline : 0755-23699909
Product Details

Contact form: Normally Open (N.O)

Max contact rating:10W

Max switch Voltage:DC100v

Max carrying Current: 1 A

Max switch current:0.5A
